Additional information
| Weight | 0.4 kg |
|---|---|
| Model | XPI-S905X4, XPI-S905X3, XPI-S905X2 |
| Please select an option |
Tax Info
ALL prices listed on Geniatech exclude taxes, import fees, and customs duties. Customers
may be subject to these fees.
Credit-card-sized High Performance Board
Geniatech XPI-S905X2 is a DIY product that uses the form factor of Raspberry Pi. Compatible with S905X3/S905X4 at the same time(S905X2, X3, X4 are p2p compatible). According to the definition of Raspberry Pi, which is suitable for the field of teaching, research, and industrial entry-level single board computer.
Compatibility and Extensibility
40 Pin header enables hardware re-use by maintaining compatible alternate pin functions like SPI, I2C, PWM, UART, and GPIO. Form-factor compatible with Raspberry Pi for easy migration.
| Extension GPIO | |||||||
| PIN | Default function | PIN | Default function | PIN | Default function | PIN | Default function |
| 1 | VCC_IO_3V3 | 2 | VCC5V | 3 | GPIOA_14 | 4 | VCC5V |
| 5 | GPIOA_15 | 6 | GND | 7 | GPIOH_7 | 8 | GPIOX_6 |
| 9 | GND | 10 | GPIOX_7 | 11 | GPIOX_11_SPI_A_SCLK | 12 | GPIOAO_2 |
| 13 | GPIOX_8_SPI_A_MOSI | 14 | GND | 15 | GPIOX_9_SPI_A_MISO | 16 | GPIOH_5_UART_CTS |
| 17 | VCC_IO_3V3 | 18 | GPIOH_4_UART_RTS | 19 | GPIOX_12_TX | 20 | GND |
| 21 | GPIOX_13_RX | 22 | GPIOX_5 | 23 | GPIOX_14_CTS | 24 | GPIOX_10_SPI_A_SS0 |
| 25 | GND | 26 | GPIOH_6_SPI_B_SS0 | 27 | GPIOX_17 | 28 | GPIOX_18 |
| 29 | GPIOX_15_RTS | 30 | GND | 31 | GPIOX_19 | 32 | GPIOAO_5_IR |
| 33 | GPIOAO_6_CLK | 34 | GND | 35 | GPIOAO_7_FS | 36 | GPIOAO_4 |
| 37 | GPIOX_4 | 38 | GPIOAO_8_TDI | 39 | GND | 40 | GPIOAO_9_TDO |
Powerful Hardware Decoding Capability
| Media Remark | Codec |
| Video/Picture Decoding | 4KP120 10 bit: AV1 (XPI-S905X4 only) |
| VP9 Profile-2 up to 4Kx2K@60fps | |
| H.265 HEVC MP-10@L5.1 up to 4Kx2K@60fps | |
| AVS2-P2 Profile up to 4Kx2K@60fps | |
| H.264 AVC HP@L5.1 up to 4Kx2K@30fps | |
| H.264 MVC up to 1080P @60fps | |
| MPEG-4 ASP@L5 up to 1080P@60fps (ISO-14496) | |
| WMV/VC-1 SP/MP/AP up to 1080P@60fps | |
| AVS-P16(AVS+) /AVS-P2 JiZhun Profile up to 1080P@60fps | |
| MPEG-2 MP/HL up to 1080P@60fps (ISO-13818) | |
| MPEG-1 MP/HL up to 1080P@60fps (ISO-11172) | |
| RealVideo 8/9/10 up to 1080P@60fps | |
| Multiple language and multiple format sub-title video support | |
| MJPEG and JPEG unlimited pixel resolution decoding (ISO/IEC-10918) | |
| Supports JPEG thumbnail, scaling, rotation and transition effects | |
| Supports *.mkv,*.wmv,*.mpg, *.mpeg, *.dat, *.avi, *.mov, *.iso, *.mp4, *.rm and *.jpg file formats |
Specifications
| Chipset | Amlogic S905X2, S905X3/S905X4 optional | |
| Software | Android 9.0 | |
| Processor
| CPU | Quad-core Cortex-A53 (S905X2) Quad-core Cortex-A55 (S905X3/X4) |
| GPU | ARM G31 MP2 GPU | |
| RAM | 1GB(2GB Optional) | |
| EMMC FLASH | 8GB（16G/32G Optional） | |
| Network | Ethernet | RJ45, 1000M |
| WiFi | Optional (Different types of wifi interface can be customized ) | |
| Bluetooth | Optional | |
| Interface | TF Card Slot | TF card *1(max. 64GB) |
| HDMI | HDMI out*1 | |
| USB | USB 2.0*3 and USB3.0*1 | |
| USB Type-C | Power IN*1 | |
| Extension GPIO | GPIO*28 | |
| UART | UART*1 | |
| Dimensions | 85 mm * 56 mm | |
| Accessory | Power Adapter, Cooling fin, WIFI Module(2.4G&5.8G / BT4.0) Optional | |
